| Temperature measuring range |
-40℃~70℃ |
| Temperature measuring accuracy |
±0.3℃ over- 20℃~+60℃, ±0.4℃ over -40℃~+70℃ |
| Reported resolution |
0.001℃ |
| Repeatability |
0.04℃ (3-sigma value of 25 measurements at constant temperature) |
| Long-term drift |
<±0.003℃ per year |
| Response time (with filter) |
120 s (63% response in air moving at 1 m/s) |
| Humidity measuring range |
0%~100%RH |
| Humidity accuracy |
(at 25℃)±1.8%RH over 0 to 80%RH, ±3%RH over 80 to 100%RH，<±1% RH (at other temperatures over -40 to +60°C) |
| Short term hysteresis |
<1% RH |
| Temperature dependence |
Compensated to<±2% over -20~60℃ |
| Typical long-term stability |
<±0.5% per year |
| Reported resolution |
0.001% RH |
| Temperature sensor |
PT100 1/3DIN |
| Humidity sensor |
Humidity capacitance |
| Supply voltage |
5V~28VDC(0~5V8V DC~28V DC 0~10V 14V DC~28V DC) |
| Output |
Analog signal: voltage 0~1V/0~2.5V/0~5V/0~10V,temperature 4-wire resistance output,digital sianal:RS485 |
| Interfaces |
8-wire,M12,RJ45 |
| Storage range |
-60℃~+90℃ |
| ESD Protection |
+25KV |
| IP class |
IP64 |
| Housing |
ABS+PC, flame-retardant, toxicity and halogen free |
| Dimensions |
Ф18.6x140mm |
| Lead wire |
2m/3m/5m (customized) |
| Weight |
26g |
